Granite Block Cutter Machine

With a focus on producing the finest Granite Block Cutter Machine, DAFON has established itself as a renowned manufacturer that prioritizes design, production, and customer satisfaction.
Price: $28900-$36900
Model Number: DF-2500/2800/3200
Power: 45/55/75KW
Application: Art & Craft, Stone Industry
Weight: 12.5/14/15.5T
Brand Name: DAFON
Certification: CE, ISO
Packaging logistics: In wooded cases with fumigation finish or wrapped with plastic film.

Get Quote

+86-18959843937

Product Description

Stone Block cutting machine Features:

The block cutter machine is mainly for granite and marble, it adopts multi-disc and PLC programmable control and man-machine interface, combined with a super-precision rotary encoder for slicing, uses frequency converter to control left-right feeding and adjusts the speed according to the stone material.stone block cutter adopts a hydraulic lifting system and forward-backward slicing adopts high-precision screw nut driving, automatic slicing, main spare parts adopt imported good-quality materials. The block can be placed on the ground directly, saving the cost of trolley and maintenance. It is especially suitable for cutting high-value granite and marble block because of high-efficiency cutting rate, high precision slicing, flatness, stability and easy operation.

Technical parameters for block cutter：

Name	DF-2500	DF-2800	DF-3000	Unit
main motor power	45	55	75	KW
Diameter of blade	Ø1600-2500	Ø1600-2800	Ø1600-3200	mm
Lifting Stroke	1250	1200	1100	mm
slicing range	2200	2200	220	mm
Blade Number	1-12	13-18	18	Pieces
cutting stroke	5000	5000	5000	mm
weight	12500	14000	15500	kg
overall dimensions(LWH)	800045006500	800045006500	800045006500	mm

the specific techniques and processes to use a granite block cutter:

1. Choose the Right Blade
Granite block cutters are equipped with a diamond blade that is capable of cutting through even the toughest granite. Before cutting, make sure that the blade is appropriate for the thickness and density of the granite you are cutting. Always use a sharp blade and replace it as needed.
2. Set Up the Machine
Ensure the granite block cutter is set up on a flat, stable surface. Adjust the machine’s cutting depth and angle to the appropriate size and position for your project.
3. Prepare the Granite
Before cutting, make sure that the granite is clean and dry, with no debris or dirt on the surface. Measure and mark the cutting line on the granite surface using a marker or tape measure.
4. Cut the Granite
Turn on the granite block cutter and slowly lower the blade onto the granite along the cutting line. Use gentle and steady pressure to cut through the granite, being careful not to exert too much force that could cause the blade to break or the granite to crack.
5. Clean and Finish the Cut
Once the cut is complete, turn off the granite block cutter and carefully remove the cut piece of granite. Use a damp cloth or sponge to clean the granite surface and remove any dust or debris. If needed, use polishing tools to smooth and refine the cut edge.
In conclusion, with the help of a granite block cutter, cutting granite can be an efficient and accurate process. Follow these techniques and processes to ensure a successful and positive outcome. Always prioritize safety and wear appropriate protective gear when operating the machine.
