Electric Kerbstone Cutting Machine

DAFON has cemented itself as a leading manufacturer of Kerbstone Cutting Machine, delivering unmatched design, manufacture, and trading.
Price: $20900-$75900
Model Number: DFLSX1200-13S
Power: 22KW&55KW
Application: Machinery & Hardware, Construction, Stone
Weight: 20T
Brand Name: DAFON
Certification: CE, ISO
Packaging logistics: In wooded cases with fumigation finish or wrapped with plastic film.

Get Quote

+86-18959843937

Product Description

The introduction of Kerbstone Cutting Machine

As a producer of curb stone cutting machine, this stone cutting machine is suitable for the production of large quantities of curb stones. The whole set of equipment only needs one worker to load and unload materials. The sliced stone is conveyed by the roller to the edge trimmer for further processing. The mature design of the assembly line operation and the machines can not only guarantee the high quantity but also high quality of the final products. Compared with traditional processing methods, labor costs are greatly reduced and a smaller production area is required to achieve the same output.

Technical Features of Kerbstone Machine

The curbstone machine is equipped with a hydraulic system, cutting with a hydraulic lift. It has a compact design that makes it easy to move and store, as well as to operate. With a high degree of automation, the stone is transferred through the roller between the two machines, saving manual loading and unloading time, and ensuring the production of curbstones with uniform thickness, width, and height.

Product Applications of Curbstone Machine

The curbstone machine is widely used in the construction industry, especially for the production of curbstones used in infrastructure projects. A curbstone machine is a specialized equipment used for the production of curbstones used for construction purposes such as roadways, walkways, driveways, and sidewalks. It is an industrial-grade machine that is designed to produce high-quality and durable curbstones in a fast and efficient manner.The machine is ideal for large-scale production, making it suitable for use in commercial and industrial projects.

Main Functions of Curbstone Machine

The main function of the curbstone machine is to produce high-quality and standardized curbstones. It is easy to operate, and the production process is fast, efficient, and reliable. Using the curbstone machine, construction companies can produce curbstones at a faster rate, which means they can complete projects faster and at a lower cost.

The Technical Date of Kerb stone Cutting Machine

Complete Machine Line (1 Edge Cutting Machine + 1 Slicing Machine)
Slicing Machine DF1200-12S		Edge Cutting Machine DF1200-1S
Dimension	6000×3000×2800mm	Dimension	6000×4000×4500mm
Diameter of blade	1200mm	Diameter of blade	1200mm
Number of blades	12pcs	Number of blades	1pcs
Max.cutting size	3000×1800×450mm	Worktable size	2500×1800mm
Worktable size	2500×1800mm	Working length max	2500mm
Weight	10t	Max.vertical stroke	600mm
Max.cutting depth	450mm	Weight	9t
Main motor power	55kw-6	Max.cutting depth	450mm
Max.vertical stroke	600mm	Main motor power	22kw-6
It produces about 30-35m³ of stone every day (24h) and covers a total space of 12m*5m.
