Granite & Marble Cutting Machines, Stone Block Cutting, Polishing and Engraving Equipment. Trusted Manufacturer with Reliable Quality & Warranty
It can polish 8 slabs of the same height simultaneously, with automatic disc changing. The computer controls the mode, number of pieces, pressure, walking speed, and water valve switch for each polishing disc.
| Name | Unit | DFB-LM3700 |
| Polishing heads | pcs | 8 |
| Max. processing size | mm | 3700*2000*1500 |
| Lifting stroke | mm | 1000 |
| Main motor | kw | 7 |
| Left and right X-axis planetary reducer | — | 1.5kw Servo Motor |
| Front and rear Y-axis gear reducer | — | 1.5kw Servo Motor |
| Weight | kg | 4500 |
| Overall dimensions (L*W*H) | mm | 6000*4500*2300 |
