Description
🔹 Easy Operation
PLC control and touch screen interface allow simple parameter setup and automated grinding.
🔹 Flexible Grinding Settings
Pneumatic control adjusts grinding head pressure, transverse speed, and feed speed within set ranges.
🔹 Automatic Plate Recognition
Automatically detects plate thickness for uniform processing depth and consistent surface effect.
🔹 High Utilisation Rate
Safe processing reduces breakage and maximizes stone plate usage.
🔹 High Efficiency & Labor Saving
Continuous operation increases productivity while minimizing manual intervention.
| Name | Unit | DFB-L6 | DFB-L8 | DFB-L10 |
| Number of heads | pcs | 6 | 8 | 10 |
| Max. Processing width | mm | 1250
(customized) |
1250
(customized) |
1250
(customized) |
| Beam swing speed | m/min | 3-35 | 3-35 | 3-35 |
| Main motor power | kw | 6*7.5kw | 8*7.5kw | 10*7.5kw |
| Beam motor power | kw | 3 | 3 | 3 |
| Belt feeding speed | m/min | 0.5-4 | 0.5-4 | 0.5-4 |
| Belt motor power | kw | 2.2 | 2.2 | 2.2 |
| Total power | kw | 48.7 | 63.7 | 78.7 |
| Air pressure | mpa | ≥0.7 | ≥0.7 | ≥0.7 |
| Water pressure | mpa | 0.1-0.15 | 0.1-0.15 | 0.1-0.15 |
| Water consumption | m³/min | ≥8 | ≥8 | ≥8 |
| Overall dimensions (L*W*H) | mm | 3400*2300*2000 | 3900*2300*2000 | 4500*2300*2000 |
