Price:
Brand Name: DAFON
Model Number: DF1200-12
Power: 55/65/75kw
Application: kerb stone cutting
Weight: 10t
Place of Origin: CHINA.
Trading Method: FOB/CIF/EXW Xiamen Port
Certification: CE, ISO
Minimum Order Quantity: 1 SET
Delivery Time:90 Days
Packaging logistics: In wooded cases with fumigation finish or wrapped with plastic film.
Full-automatic kerbstone cutting line is a kind of high efficiency, energy saving, intelligent production equipment, according to the demand for automatic adjustment of the cutting width, size and angle and other parameters, through the calculation, programming and sensors and other technologies to achieve automatic identification, to achieve accurate cutting and processing, improve product quality and process level, an assembly line only needs a worker, to complete the cutting of the road stone, the length of the road stone chamfering to the road stone process, greatly improve the production capacity and quality of production, reduce the cost of production, and increase the profit of the enterprise.
Name | Unit | DF1200-12 |
Max.blade diameter | mm | 1000-1200 |
Max.number of saw blades | pcs | 20 |
Max.processing width | mm | 1550/1750/1950 |
Effective shaft length |
mm |
1750 |
Spindle diameter | mm | 120 |
Max.lifting stroke | mm | 600 |
Max.depth of cut | mm | 450 |
Main motor power | kw | 55/65/75 |
Worktable size (L*W*H) | mm | 2500*1600/1800/2000*450 |
Weight | t | 10 |
Overall dimensions(L*W*H) | mm | 6000*5500*3100 |
T-shaped Kerb stone: often used in traffic islands, pedestrian bridges and other places to prevent vehicles from crossing illegally. ...
L-shaped Kerb stone : suitable for road edges, which can effectively guide the walking direction of vehicles and pedestrians. U-shaped Kerb stone : suitable for side...
U-shaped Kerb stone: suitable for sidewalks or public squares, etc. Its curved design helps improve pedestrian safety and comfort. ...
Machinepart The machine line included one slicing machine(DF1200-12S) and one edge cutting machine(DF1200-1S), worker load thick slab to the slicing machine with a crane, after s...
Kerb stone cutting machine features: Note:if single DF1200-12 is required, roller on worktable is no need Kerb stone cutting machine advantages: 1. No foundation needed, easy instal...
Introduction of kerbstone chamfering machine The chamfering machine adopts an enlarged frame design, which is sturdy and durable, ensuring excellent performance in long-term use. ...
